Type Leakage capacitance of the component
C
ab
nF
MSK101C-0200-FN-__-___-
____
6,2
MSK101D-0200-FN-__-___-
____
13,2
MSK101E-0200-FN-__-___-
____
15,2
MSK103A-0300-NN-__-___-
____
1,5
MSK103B-0300-NN-__-___-
____
2,1
MSK103D-0300-NN-__-___-
____
6,0
MSK131B-0200-NN-__-___-
____
14,3
MSK131D-0200-NN-__-___-
____
27,7
Last modification: 2012-09-17
Tab. 11-8: MSK - Leakage Capacitance (Excerpt)
See also Rexroth IndraDyn - Technical Data.
11.3.2 Leakage Capacitance of Power Cables
The power cables (bulk cables) of the "RKL" line by Rexroth have the capaci‐
tances per unit length listed below. The values refer to the sum of the single
capacitances of power cores 1, 2 and 3 against the overall shield.
See also Rexroth Connection Cables - Data Sheet Bulk Cables.
Data Sheet Excerpt- Bulk Cables
Type Cross section of power core Leakage capacitance
mm
2
C
Y_K_typ
nF/m
INK0653 1,0 0,6
INK0650 1,5 0,8
INK0602 2,5 0,7
INK0603 4,0 0,8
INK0604 6,0 0,8
INK0605 10,0 1,0
INK0606 16,0 1,2
INK0607 25,0 1,1
Last modification: 2007-11-08
Bosch Rexroth AG DOK-INDRV*-HCS01******-PR05-EN-P328/341
Rexroth IndraDrive CsDrive Systems with HCS01
Appendix
