4.3.4 Motors
IndraDyn
The table below contains an overview of the combinations of MSM motors
with HCS01 converters.
Motor
HCS01
Size 1 Size 2 Size 3
3 AC 110 … 230 V 3 AC 200 … 500 V
W0003 W0006 W0009 W0013 W0018 W0005 W0008 W0018 W0028 W0054
MSM019A ■ □ □ □ - T T - - -
MSM019B ■ □ □ □ - T T - - -
MSM031B × ■ □ □ - T T - - -
MSM031C - × ■ □ - T T - - -
MSM041B - - × ■ □ - T T - -
■ Optimum combination
□ Allowed combination (converter overdimensioned)
× Allowed combination (motor overdimensioned)
T Allowed combination (transformer required, as operation of
MSM motors only allowed with a maximum of 3 AC 230 V)
- Combination not allowed
Tab. 4-7: Combination of HCS01 converters and MSM motors
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 47/341
Rexroth IndraDrive CsDrive Systems with HCS01
Combining the individual components
