Bosch Rexroth IndraDrive CsDrive System with HCS01 User Manual

Country of use: international except for USA/Canada
Fuse I
N
[A] Current carrying ca‐
pacity (× 0.87) I
Z(40)
[A]
Cross section A [mm
2
]
Installation type B1
1 × 2 × 3 ×
400 342.78 300
315 160 238.03 2 × 70
400 160 288.14 2 × 95
400 200 332.69 2 × 120
400 200 364.70 2 × 150
500 250 412.03 2 × 185
630 315 481.63 2 × 240
630 315 548.45 2 × 300
400 125 312.42 3 × 70
500 160 378.19 3 × 95
500 160 436.65 3 × 120
630 200 478.67 3 × 150
630 200 540.79 3 × 185
800 250 632.14 3 × 240
800 315 719.84 3 × 300
Tab. 4-26: Line cross sections and fuses, B1 according to EN 60204-1:2006,
Table 6, for 150mm² and more DIN IEC 60364-5-52:2004, Table B.
52-4
International except for USA/
Canada; installation type B2
Country of use: international except for USA/Canada
Fuse I
N
[A] Current carrying ca‐
pacity (× 0.87) I
Z(40)
[A]
Cross section A [mm
2
]
Installation type B2
1 × 2 × 3 ×
2 1.6 0.75
4 3.3 0.75
6 5.0 0.75
10 8.5 0.75
16 10.1 1.0
16 13.05 1.5
20 17.40 2.5
25 23.49 4
35 29.58 6
50 40.02 10
63 53.94 16
80 69.60 25
Bosch Rexroth AG DOK-INDRV*-HCS01******-PR05-EN-P88/341
Rexroth IndraDrive CsDrive Systems with HCS01
Combining the individual components
