Fuji Xerox Phaser 5500 User Manual

Error Messages, Codes, and Procedures 3-37
Jam at A - E1-2 Regi Area Jam
Paper did not activate the Fuser Exit Sensor, located behind Door A, within the
specified time following activation of the Registration Clutch.
Applicable Error Code
Jam at A - E1-2 Regi Area Jam
10
Check for +24 V to the Registration Clutch.
Is there +24 V across P215-2 (+) <=>
ground?
Go to Step 11. Replace the
Engine Logic
Board
(
page 8-89).
11
Check Registration Clutch resistance.
Is the resistance between J215-1 and
J215-2 approximately 240 ohms?
Replace the
Engine Logic
Board
(
page 8-89).
Replace
Registration
Clutch
(
page 8-51).
E1-2 Regi Area Jam (Fuser Exit Sensor) Troubleshooting Reference
Applicable Parts References
■ Fuser Exit Sensor
■ Registration Clutch
■ Take Away Roller
■ Exit PWB
■ Engine Logic Board
■ Print Engine P/J Drum and Toner Cartridge
(page 10-6)
■ Print Engine Exit 1 Wiring (page 10-30)
■ PL4.1 Transportation and Registration (page 9-22)
■ PL4.5 Registration (page 9-30)
■ PL6.1 Laser, CRU, and Toner Dispense (page 9-32)
■ PL8.1 Print Engine Electrical (page 9-40)
E1-2 Regi Area Jam (Fuser Exit Sensor) Troubleshooting Procedure
Step Actions and Questions Yes No
1
Check paper position behind Door A.
Does the paper touch the Fuser Exit
Sensor?
Remove the
paper.
Go to Step 2.
2
Check the Take Away Roller.
Is the Take Away Roller worn or
contaminated with paper dust?
Clean or replace
the Take Away
Roller.
Go to Step 3.
Paper Size Jam (Registration Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
