8-2 Phaser 5500 Printer Service Manual
Overview
This section contains the removal and replacement procedures for spared parts
according to the Field Replaceable Units (FRUs) Parts List. Replacement procedures
are not provided for most of the FRUs because in most cases, re-installing a part only
requires reversing the removal procedure. Where the replacement process is not a
simple reversal of the removal, a replacement procedure is included. Replacement
Notes provide tips and suggestions that can aid in reassembling the part.
Standard Orientation of the Printer
Locations given in the repairs, such as left, right, front, or rear, assume you are facing
the printer Front Panel. When needed the orientation of the printer is called out in the
procedure for locating printer parts, refer to the printer orientation graphic for
locating the right, left, front and back sides of the printer
s5500-075
Front
Rear
Right
Left
