10-28 Phaser 5500 Printer Service Manual
Tray 1/MPT
Engine
Logic Board
P/J411
4
+24VDC
5
Pick Up Solenoid On(L)+24VDC
P205
2
1
1
2
Pick Up Solenoid
J411
1
2
3
J107
1
2
3
Tray 1/MPT
Paper Size Sensor
Tray 1/MPT Size Sensor Signal
SG
+5VDC
P605
8
J605
1
7 2
6 3
+5VDC
+24VDC
P609
3
J609
1
2 2
1 3
P605
5
J605
4
4 5
P/J108
3
2
1
P605
3
J605
6
2 7
1 8
P/J411
6
7
8
+5VDC
Tray 1/MPT Paper Sensed(L)+5VDC
SG
+5VDC
s5500-227
Tray 1/MPT
No Paper Sensor
