3-98 Phaser 5500 Printer Service Manual
Jam at F - F4-36 X’port Ent. SNR Static
Remaining paper is detected in the Finisher Transport Entrance Sensor.
Applicable Error Code
Jam at F - F4-36 X’port Ent. SNR Static
17
Check the harness connections.
Are P/J8319 and P/J8303 of the X’port
Entrance Sensor, and P/J8302A on the
Main SNR harness connected?
Go to Step 19. Reconnect and
go to Step 18.
18
Print a Test Print.
Does the error still occur?
Go to Step 19. Problem solved.
19
Check the sensor harness continuity.
1. Disconnect P/J8319 and P/J8303B on
the X’port Entrance Sensor Harness.
2. Check for continuity at the following:
J8319-3 <=> J8303B-1
J8319-2 <=> J8303B-2
J8319-1 <=> J8303B-3
Are these conductive?
Go to Step 20. Repair the X’port
Entrance Sensor
Harness.
20
Check Main Sensor Harness continuity.
Disconnect P/J8303 on the Main Sensor
Harness, and P/J8302A on the Finisher
Main PWB.
Check for continuity at the following:
J8303A-3 <=> J8302A-1
J8303A-2 <=> J8302A-2
J8303A-1 <=> J8302A-3
Are these conductive?
Go to Step 21. Repair the Main
Sensor Harness.
21
Check for +5 V to the X’port Entrance
Sensor
Is there +5 V across J8302A-3 <=>
J8302A-1 on the Finisher Main PWB?
Go to Step 22. Replace the
Finisher Main
PWB
(
page 3-248).
22
Check the X’port Entrance Sensor signal.
Does the voltage across P8302A-2 <=>
P8302A-1 on the Finisher Main PWB
change when the sensor is blocked?
Replace the
Finisher Main
PWB
(
page 3-248).
Replace X’port
Entrance Sensor
(
page 3-117).
Jam at F (Transport Entrance Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
To Next Page
