Error Messages, Codes, and Procedures 3-233
Punch Waste Box is Full
The Punch Box counter has reached its maximum count.
5
Check Punch Sensor Harness continuity.
1. Disconnect P/J8355 and P/J8307.
2. Check for continuity at the following:
J8355-3 <=> J8307-A3
J8355-2 <=> J8307-A2
J8355-1 <=> J8307-A1
Are these conductive?
Go to Step 6. Repair the Punch
Sensor Harness.
6
Check for +5 V to the Punch Box Set
Sensor
Is there +5 V across J8307-A1 <=>
J8307-A3 on the Finisher Main PWB?
Go to Step 7. Replace the
Finisher Main
PWB
(
page 3-248).
7
Check the Punch Box Set Sensor signal.
Does the voltage across P/J8307-A2 <=>
P/J8307-A3 on the Finisher Main PWB
change when the Punch Box is removed
or replaced?
Go to Step 8. Replace the
Punch Box Set
Sensor
(
page 3-154).
8
Replace the Finisher Main PWB.
Does the error still occur?
Replace the
Engine Logic
Board
(
page 8-89).
Problem solved.
Punch Box Full (Punch Box Counter) Troubleshooting Reference
Applicable Parts References
■ Punch Box Set Sensor
■ Punch Box Sensor
Harness
■ Punch Sensor
Harness
■ Finisher Main PWB
■ Engine Logic Board.
■ Phaser 5500 Printer Options Service Manual
■ Finisher Main PWB P/J Locator (page 5-35)
■ Finisher Punch P/J Locator (page 5-31)
■ Finisher Punch (1/2) Wiring (page 5-46)
■ PL8.1 Print Engine Electrical (page 9-40)
■ PL25.7 Finisher Punch (page 4-56)
■ PL25.14 Finisher Electrical (page 4-70)
■ PL25.15 Finisher Harness (page 4-72)
Punch Box Missing (Punch Box Set Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
