3-174 Phaser 5500 Printer Service Manual
Punch Failure - H5-3n Home SNR
The Punch Unit Move Home Sensor does not change state within the specified time
following activation of the Punch Move Motor or the Move Home sensor changes
state after the Punch Move Motor has stopped.
Applicable Error Codes
Punch Failure - H5-33 Home SNR ON
Punch Failure - H5-34 Home SNR OFF
10
Check the harness connections.
Are P/J8345 and P/J8332 on the Punch
Harness, and P/J8332 and P/J8306 on
the Punch Drive Harness connected?
Go to Step 12. Connect and go
to Step 11.
11
Print a Test Print.
Does the error still occur?
Go to Step 12. Problem solved.
12
Check Punch Motor Harness continuity.
1. Disconnect P/J8345 and P/J8332.
2. Check for continuity at the following:
P/J8345-2 <=> P/J8332-2
P/J8345-1 <=> P/J8332-1
Are these conductive?
Go to Step 13. Repair the Punch
Harness.
13
Check Punch Motor Drive Harness
continuity.
1. Disconnect P/J8332 and P/J8306.
2. Check for continuity at the following:
P/J8332-2 <=> P/J8306-8
P/J8332-1 <=> P/J8306-7
Are these conductive?
Go to Step 14. Repair the Punch
Motor Drive
Harness.
14
Replace the Punch Motor.
Punch a Test Print.
Does the error still occur?
Replace the
Finisher Main
PWB
(
page 3-248).
Problem solved.
Punch Failure (Punch Home Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
