Error Messages, Codes, and Procedures 3-115
Jam at H - F4-56 Compile Exit SNR Static
Remaining paper is detected by the Compile Exit Sensor.
Applicable Error Codes
Jam at H - F4-56 Compile Exit SNR Static
26
Check Main Sensor Harness continuity.
1. Disconnect P/J8391 from the harness,
and P/J8302A on the Finisher Main
PWB.
2. Check for continuity at the following:
J8391A-3 <=> P/J8302A-4
J8391A-2 <=> P/J8302A-5
J8391A-1 <=> P/J8302A-6
Are these conductive?
Go to Step 9. Repair the Main
Sensor Harness.
27
Check for +5 V to the Compile Exit Sensor.
Is there +5 V across J8302A-6 <=>
J8302A-4 on the Finisher Main PWB?
Go to Step 10. Replace the
Finisher Main
PWB
(
page 3-248).
28
Check Compile Exit Sensor signal.
Does the voltage across P8302A-5 <=>
P8302A-4 on the Finisher Main PWB
change when the actuator is operated?
Replace the
Finisher Main
PWB
(
page 3-248).
Replace the
Compile Exit
Sensor
(
page 3-189).
Static Jam at H (Compile Exit Sensor) Troubleshooting Reference
Applicable Parts References
■ Compile Exit Sensor
■ Compiler Harness
■ Main Sensor Harness
■ Finisher Main PWB
■ Main Drive Harness
■ Exit Motor
■ Phaser 5500 Printer Options Service Manual
■ Finisher Main PWB P/J Locator (page 5-35)
■ Finisher Sensors (1/2) Wiring (page 5-40)
■ Finisher Motors Wiring (page 5-42)
■ PL25.10 Finisher Eject (2/3) (page 4-62)
■ PL25.11 Finisher Eject (3/3) page 4-64)
■ PL25.13 Finisher Transport (2/2) (page 4-68)
■ PL25.14 Finisher Electrical (page 4-70)
■ PL25.15 Finisher Harness (page 4-72)
Jam at F or G (Compile Exit Sensor ON) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
