10-22 Phaser 5500 Printer Service Manual
Fuser
Engine Logic
Board
P/J401
5
Main Lamp On(H)+5VDC
4
3
P/J525
1
2
3
2 4
51
LVPS Fuser
P/J6
2
3
4
1
Sub Lamp1 On(H)+5VDC
Sub Lamp2 On(H)+5VDC
Relay On(L)+24VDC
Zero Cross
P/J600
1
4
7
11
Heater
Control
P/J410
7
6
P607
1
J607
6
2 5
P/J600
2
3
Center STS Signal
SG
Center
STS
P131
2
1
5 3 4 5
2ND STS Signal
P132
1
4 4 3 6
SG
2
3 5 2 8
Rear STS Signal
P133
1
2 6 1 9
SG
2
2nd
STS
Rear
STS
P/J125
3
2
1
P/J410
8
9
10
+5VDC
Fuser Exit Paper Sensed(L)+5VDC
SG
+5VDC
Fuser Exit Sensor
s5500-221
