3-38 Phaser 5500 Printer Service Manual
Jam at A - E1-6 Regi Area Jam
Paper remains at the Registration Sensor located behind Door A.
Applicable Error Code
Jam at A - E1-6 Regi Area Jam
3
Test the Fuser Exit Sensor.
1. Open Door A.
2. Run the Service Diagnostics Fuser Exit
Sensor test.
Does the sensor change state?
Go to Step 7. Go to Step 4.
4
Check the Fuser Exit Sensor connection.
Are P/J125 and P/J410 connected?
Go to Step 5. Connect the
sensor.
5
Check continuity between the Fuser Exit
Sensor and Engine Logic Board.
Is there continuity on each wire
between P/J125 <=> P/J410?
Go to Step 6. Repair the wiring.
6
Check for +5 V at the Fuser Exit Sensor.
Is there +5 V across the sensor
connector’s P/J125-3 <=> ground?
Replace the Fuser
Exit Sensor
(
page 8-77)
Replace the
Engine Logic
Board
(
page 8-89).
7
Test the Registration Clutch operation.
Run the Service Diagnostics Registration
Clutch test.
Does the clutch operate properly?
Replace the
Engine Logic
Board
(
page 8-89).
Go to Step 8.
8
Check the Registration Clutch connection.
Are P/J215 and P/J403B connected?
Go to Step 9. Connect P/J215
and P/J403B.
9
Check continuity between the Registration
Clutch and Engine Logic Board.
Is there continuity on each wire
between P/J215 <=> P/J403B?
Go to Step 10. Repair the wiring.
10
Check for +24 V to the Registration Clutch.
Is there +24 V across P215-2 (+) <=>
ground?
Go to Step 11. Replace the
Engine Logic
Board
(
page 8-89).
11
Check Registration Clutch resistance.
Is the resistance between J215-1 and
J215-2 approximately 240 ohms?
Replace the
Engine Logic
Board
(
page 8-89).
Replace
Registration
Clutch
(
page 8-51).
E1-2 Regi Area Jam (Fuser Exit Sensor) Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
