Fuji Xerox Phaser 5500 User Manual

Error Messages, Codes, and Procedures 3-245
Close Door G - Door G is Open
The Door G Interlock Switch behind the Finisher Front Door indicates Door G is
open.
Door G Open (Door G Interlock Switch) Troubleshooting Reference
Applicable Parts References
■ Finisher Front
Cover
■ Door G Interlock
Switch
■ Interlock Harness
■ Eject Cover Sensor
■ Finisher Main PWB
■ Engine Logic
Board.
■ Print Engine P/J Engine Logic Board (page 10-13)
■ PL8.1 Print Engine Electrical (page 9-40)
■ Phaser 5500 Printer Options Service Manual
■ Finisher P/J Locator Door G Interlock (page 5-30)
■ Finisher Main PWB P/J Locator (page 5-35)
■ Finisher Power Wiring (page 5-38)
■ PL25.5 Finisher Covers (2/2) (page 4-52)
■ PL25.9 Finisher Eject (1/3) (page 4-60)
■ PL25.14 Finisher Electrical (1/2) (page 4-70)
■ PL25.15 Finisher Electrical (2/2) (page 4-72)
Door G Open (Door G Interlock Switch) Troubleshooting Procedure
Step Actions and Questions Yes No
1
Check Door G operation.
Does Door G open and close smoothly?
Go to Step 2. Correct the
installation.
2
Check the Door G Interlock Switch
installation.
Is the sensor installed correctly?
Go to Step 3. Correct the
installation.
3
Test the Door G Interlock Switch.
Run the Service Diagnostics Door G
Interlock Switch test.
Does the sensor state change when
Door G is opened and closed?
Go to Step 9. Go to Step 4.
4
Check the Door G Interlock Harness
connections.
Are J8365 on the harness, J8364 on the
Eject Cover SW, and J8388 and J8314
on the Finisher Main PWB connected?
Go to Step 6. Connect and go
to Step 5.
5
Cycle printer power.
Does the error still occur?
Go to Step 6. Problem solved.
