3-228 Phaser 5500 Printer Service Manual
Stapler Failure - Staple Failure
The status of the Staple Home Sensor is not determined within the time specified
following a Stapler Move Motor forward operation. For Staple Move Motor reverse,
the Staple Home Sensor is not turned On in the time specified.
Stapler Failure (Staple Head Home Sensor) Troubleshooting Reference
Applicable Parts References
■ Finisher Main PWB
■ Staple Harness
■ Stapler Assembly
■ Engine Logic Board.
■ Phaser 5500 Printer Options Service Manual
■ Finisher Main PWB P/J Locator (page 5-35)
■ Finisher Staple P/J Locator (page 5-30)
■ Finisher Stapler Wiring (page 5-45)
■ PL25.8 Finisher Staple (page 4-58)
■ PL25.14 Finisher Electrical (page 4-70)
Stapler Failure (Staple Head Home Sensor) Troubleshooting Procedure
Step Actions and Questions Yes No
1
Check the Compiler Tray for obstructions.
Are there any obstructions in the
Compiler Tray?
Remove the
obstacles.
Go to Step 2.
2
Test the Staple Motor in the Staple Head.
Run the Service Diagnostics Staple Motor
Forward and Reverse tests alternately.
Does the Staple Motor operate?
Go to Step 6. Go to Step 3.
3
Check the Staple Motor Harness
connections.
Are P/J8357 and P/J8308 connected?
Go to Step 5. Connect and go
to Step 4.
4
Cycle the printer power.
Does the error still occur?
Go to Step 5. Problem solved.
5
Check Staple Motor Harness continuity.
1. Disconnect P/J8357 and P/J8308.
2. Check for continuity at the following:
J8357-1 <=> J8308-10
J8357-2 <=> J8308-9
J8357-3 <=> J8308-8
J8357-4 <=> J8308-7
Are these conductive?
Go to Step 11. Repair the Staple
Harness.
6
Test the Staple Head Home Sensor.
Run the Service Diagnostics Staple Head
Home Sensor test.
Does the sensor state change when the
Staple gear is rotated?
Go to Step 12. Go to Step 7.
