Fuji Xerox Phaser 5500 User Manual

Error Messages, Codes, and Procedures 3-79
Jam at Tray 6 - C8-5 HCF F/O SNR Static Jam
Remaining paper in the Tray 6 Feed Out Sensor #6, located in the Lower Feeder
Assembly under Door J.
Applicable Error Code
Jam at Tray 6 - C8-5 HCF F/O SNR Static Jam
5
Check continuity between 1000-Sheet
Feeder and Engine Logic Board.
Is there continuity on each wire
between P/J541 <=> P/J413?
Go to Step 6. Repair the wiring.
6
Check for +5 V to the Feed Out Sensor #5.
Is there +5 V across P/J825-3 (+) <=>
ground?
Replace the Feed
Out Sensor #5
(
page 3-22).
Go to Step 7.
7
Check +5 V to the Tray 4-5 PWB.
Is there +5 V across P/J548-1 (+) <=>
ground?
Replace the Tray
4-5 PWB
(
page 3-29).
Replace the
Engine Logic
Board
(
page 8-89).
Jam at Tray 6 (Feed Out Sensor #6) Troubleshooting Reference
Applicable Parts References
■ Feed Roller
■ Retard Roller
■ Take Away Roller
■ Door J
■ Pre-Feed Sensor
■ Feed Out Sensor #6
■ Feeder Harness
■ Main Harness
■ Take Away Motor
■ Feeder Motor
■ Tray 6 PW B
■ Engine Logic Board)
■ Print Engine P/J Engine Logic Board (page 10-13)
■ PL8.1 Print Engine Electrical (page 9-40)
■ Phaser 5500 Printer Options Service Manual
■ 2000-Sheet Tray 6 Feeder P/J (page 5-20)
■ 2000-Sheet Tray 6 Drive P/J (page 5-21)
■ 2000-Sheet Tray 6 Sensors Wiring (page 5-24)
■ 2000-Sheet Tray 6 Drive Wiring (page 5-25)
■ PL22.4 Tray 6 Feeder (1/3) (page 4-24)
■ PL22.5 Tray 6 Feeder (2/3) (page 4-26)
■ PL22.6 Tray 6 Feeder (3/3) (page 4-28)
■ PL22.7 Drive and Transportation (page 4-30)
■ PL22.8 Tray 6 Electrical (page 4-32)
Jam at C (Feed Out Sensor #5) Troubleshooting Procedure (Continued)
