Reference A-23
Saving Engine Logic Board NVRAM
To save the Engine Logic Board’s NVRAM contents to the I/P Board:
1. Enter Service Diagnostics.
2. Select Save from Engine Board from the Engine Logic Board Replacement
menu and press OK.
Data is transferred from the Engine Logic Board to a reserved location on the
Image Processor Board. During the process the Front Panel will display "Saving
NVRAM" once the routine is completed the front panel will display "Save
Complete"
3. Power the printer off and replace the Engine Logic Board
Restoring Engine Logic Board NVRAM
To restore the Engine Logic Board NVRAM to the new board:
1. Re-enter Service Diagnostics.
2. Select Restore to Engine Board from the Engine Logic Board Replacement
menu and press OK.
Data is transferred from the reserved location on the Image Processor to the
replaced Engine Logic board. During the process the front panel will display
"Restoring NVRAM" once the routine is completed the front panel will display
"Restore Complete"
3. Exit diagnostics.
Finisher Board Setup Menu
This menu allows you to reset the Punch configuration of the Finisher/Stacker.
Exit
Reboot the printer out of Service Diagnostics.
Finisher Board Setup Utilities
Utility Action / Requirement
Read Current Status Displays the current Punch setting of the Finisher Main PWB.
Set 3-Hole Punch &
Staple
Sets the Finisher Main PWB to support a 3-hole Punch and Stapler.
Set 2- /4-Hole Punch
& Staple
Sets the Finisher Main PWB to support a 2- /4-hole Punch and
Stapler.
Set No Punch &
Staple
Sets the Finisher Main PWB to a Stacker configuration with no
Punch or Stapler.
