4-6 Phaser 5500 Printer Service Manual
Finisher LVPS
3
Check DC supply voltage to the Engine
Logic Board:
1. Remove the I/P Board Cover, Upper,
and Lower Rear Covers.
2. Turn the printer power On.
3. Measure the voltage at these points:
P/J526- 2 <=> ground +5.0 V
P/J526- 4 <=> ground +24.0 V
Are the voltage levels correct?
Go to Step 4. Replace the LVPS
(
page 8-92). If the
problem persists, verify
the wire harness to the
Engine Logic board. If
the wiring checks out,
replace the Engine
Logic Board
(
page 8-89).
4
Check DC supply voltage to the Exit PWB:
1. Remove the Top Cover.
2. Turn the printer power On.
3. Measure the voltage at these points:
P/J526- 6 < = > ground +5.0V
P/J526- 8 < = > ground +24.0V
Are the voltage levels correct?
All voltages
are present
and problem
persists,
replace the
LVPS
(
page 8-92).
Replace the LVPS, if
problem continues
verify the wire harness
to the Exit PWB. If the
wiring checks out,
replace the Exit PWB
(
page 8-88).
Finisher LVPS Troubleshooting Reference
Applicable Parts References
■ LVPS
■ Power Cord
■ Printer AC
Accessory Panel
■ Phaser 5500 Printer Options Service Manual
■ Finisher LVPS Plug/Jack Locator (page 5-35)
■ Finisher Power Wiring Diagram (page 5-38)
■ PL25.14 Finisher Electrical (page 4-70)
Finisher LVPS Troubleshooting Procedure
Step Actions and Questions Yes No
1
Check AC supply voltage to the LVPS.
1. Remove the Bottom Cover.
2. Check that the Finisher power cord is
connected to the printer’s AC Accessory
Panel and turn the printer power On.
3. Measure AC voltage at the following test
points on the LVPS:
J2- 3 <=> J2- 4 120 V (120 Volt Printer)
J2- 3 <=> J2- 4 220 V (220 Volt Printer)
Are the voltages within specification?
Go to Step 2. Verify the
printer’s AC
Accessory Panel
is delivering
power.
Print Engine LVPS Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No
