Garmin G1000 Diamond DA42NG User Manual

Garmin G1000 Pilot’s Guide for the Diamond DA42NG
190-00-00962-02 Rev. A
284
HAZARD AVOIDANCE
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICESINDEX
SiriusXM Weather Product
GFDS Worldwide Weather
Product
FIS-B Weather Product
Next-generation Radar
(NEXRAD)
Precipitation
(PRECIP)
Precipitation
(PRECIP)
Cloud Top
(CLD TOP)
Infrared Satellite
(IR SAT)
Not Available
XM Lightning
(XM LTNG)
GFDS Lightning
(DL LTNG)
Not Available
SIGMETs/AIRMETs
(SIG/AIR)
SIGMETs/AIRMETs
(SIG/AIR)
Not Available
Meteorological Aerodrome Report
(METARs)
Meteorological Aerodrome Report
(METARs)
Meteorological Aerodrome Report
(METARs)
Winds Aloft
(WIND)
Winds Aloft
(WIND)
Not Available
Pilot Weather Report
(PIREPs)
Pilot Weather Report
(PIREPs)
Not Available
Table 6-3 Shared Weather Data Link Map Settings for Corresponding Data Link Weather Products
EachactiveSiriusXMWeatherproducthasanassociatedlegendwhichcanbedisplayedontheWeatherData
Link(XM)PageandNavigationMapPage.
Viewing legends for displayed weather products on the Weather Data Link (XM) Page:
1) Select the Weather Data Link (XM) Page with the FMS Knob.
2) Select the LEGEND Softkey to display the legends for the displayed weather products.
Or:
1) Press the MENU Key.
2) Select Weather Legend and press the ENT Key.
3) Turn the FMS Knob to scroll through the legends if more are available than fit in the window.
4) To remove the XM Weather Legends Window, select the LEGEND Softkey, the ENT or the CLR Key, or press the
FMS Knob.
Viewing legends for displayed weather products on the Navigation Map Page:
1) Select the Navigation Map Page with the FMS Knob.
2) Press the MAP Softkey.
3) Press the LEGEND Softkey to display the legends for the displayed weather products.
4) To remove the XM Weather Legends Window, press the LEGEND Softkey, the ENT or the CLR Key, or press the
FMS Knob.
Additionalinformationaboutthefollowingcanbedisplayedbypanningoverthedisplayonthemap:
