Garmin G1000 Diamond DA42NG User Manual

Garmin G1000 Pilot’s Guide for the Diamond DA42NG
190-00-00962-02 Rev. A
408
HAZARD AVOIDANCE
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICESINDEX
“Non-Bearing” Traffic
(System Unable to
Determine Bearing)
Distance is 4.0 nm,
500’ Above,
Descending
Non-Threat
Traffic,
Altitude Not
Reported
Off-Scale Traffic
Advisory
400’ Below, Level
Traffic Status Banner
Annunciations
Traffic Mode Annunciation
“TIS Not Available”
Voice Alert Status
Select
to Mute
“TIS Not
Available”
Voice Alert
Figure 6-162 Traffic Map Page
Traffic Advisory, 500’
Below, Climbing
Non-Threat
Traffic, 2500’
Above,
Descending
Range
Marking
Rings
TIS ALERTS
WhenthenumberofTAsontheTrafcMapPageincreasesfromonescantothenext,thefollowingoccur:
•Asingle“Traffic” voice alert is generated.
•A‘TRAFFIC’AnnunciationappearstothetopleftoftheAttitudeIndicatoronthePFD,ashingfor5seconds
andremainingdisplayeduntilnoTAsaredetectedinthearea.
•ThePFDInsetMapisautomaticallydisplayedwithtrafc.
Toreducethenumberofnuisancealertsduetoproximateaircraft,the“Traffic” voice alert is generated only
whenthenumberofTAsincreases.Forexample,whentherstTAisdisplayed,avoiceandvisualannunciation
aregenerated.AslongasasingleTAremainsonthedisplay,noadditionalvoicealertsaregenerated.Ifasecond
TAappearsonthedisplayorifthenumberofTAsinitiallydecreasesandthensubsequentlyincreases,another
voice alert is generated.

Garmin G1000 Diamond DA42NG Specifications

General

Display Type	LCD
Resolution	1024 x 768 pixels
Manufacturer	Garmin
Aircraft	Diamond DA42NG
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Audio Panel	Yes, integrated
Operating System	Proprietary
Weather Radar	Optional
Power Supply	28 VDC
Screen Size	10.4 inches
Number of Displays	2
AHRS	Yes
Air Data Computer (ADC)	Yes
GPS	Yes
Transponder	Yes
Input Method	knobs
Navigation	VOR, ILS, GPS
Traffic Avoidance	TAS/TCAS
Terrain Awareness	Yes, TAWS
