Garmin G1000 Pilot’s Guide for the Diamond DA42NG
190-00962-02 Rev. A
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICESINDEX
600
APPENDIX B
8) Press the NO Softkey. The display now starts in normal mode. Since the database effective date is not yet valid,
it should not be loaded as the active database. The display now starts in normal mode. Do not remove power
while the display is starting.
9) Press the ENT Key to acknowledge the startup screen.
10) Turn the large FMS Knob to select the AUX Page group on the MFD.
11) Turn the small FMS Knob to select the System Status Page.
12) The new database is copied to the SD card in the bottom card slot of the PFD. Progress can be monitored in the
SYNC STATUS field. When copying is finished, ‘Complete’ is displayed.
13) Turn system power OFF.
14) Remove the SD card from the top card slot of the MFD.
15) Turn system power ON.
16) Press the ENT Key to acknowledge the startup screen.
17) Turn the large FMS Knob to select the AUX Page group on the MFD.
18) Turn the small FMS Knob to select the System Status Page.
19) Press the Display Database Selection Softkey to show standby navigation database information for each display.
Verify the correct standby navigation database cycle information is shown for each display.
NOTE: The system compares the active databases on the PFD and the MFD, and displays a system alert
message ‘DB Mismatch’ if they are not identical. Similarly, if the standby databases on the PFD and the MFD
are not identical, the system will display a ‘DB Mismatch’ alert for the standby navigation databases.
GARMIN DATABASES
The following databases are stored on Supplemental Data Cards provided by Garmin:
•Expandedbasemap
•Terrain
•Airportterrain
•Obstacle
•SafeTaxi
•FliteCharts
•AirportDirectory
(AOPA or AC-U-
KWIK)
After subscribing to the desired database product, these database products will be downloaded and ultimately
stored on three Supplemental Data Cards (with the exception of FliteCharts, which is loaded on only one card).
Each Supplemental Data Card resides in the bottom card of each display as shown in Figure B-4. These cards
must not be removed except to update the databases stored on each card.
