Garmin G1000 Diamond DA42NG User Manual

190-00962-02 Rev. A
Garmin G1000 Pilot’s Guide for the Diamond DA42NG
565
ADDITIONAL FEATURES
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
8.11 FLIGHT DATA LOGGING
NOTE: Some aircraft installations may not provide all aircraft/engine data capable of being logged by the
system.
TheFlightDataLoggingfeaturewillautomaticallystorecriticalightandenginedataonanSDdatacard(up
to16GB)insertedintothetopcardslotoftheMFD.Approximately1,000ighthourscanberecordedforeach
1GB of available space on the card.
DataiswrittentotheSDcardonceeachsecondwhiletheMFDispoweredon.Allightdataloggedona
specific date is stored in a file named in a format which includes the date, time, and nearest airport identifier. The
file is created automatically each time the G1000 system is powered on, provided an SD card has been inserted.
The status of the Flight DataLoggingfeaturecanbeviewedontheAUX-UTILITYPage.IfnoSDcardhasbeen
inserted,“NOCARD”isdisplayed.WhendataisbeingwrittentotheSDcard,“LOGGINGDATA”isdisplayed.
The.csvlemaybeviewedwithMicrosoftExcel
®
or other spreadsheet applications.
ThefollowingisalistofdataparameterstheG1000systemiscapableofloggingfortheDA42NGaircraft.
•Date
•Time
•GPSaltitude(MSL)
•GPSaltitude(WGS84datum)
•Baro-Correctedaltitude(feet)
•BaroCorrection(in/Hg)
•Indicatedairspeed(kts)
•Verticalspeed(fpm)
•GPSverticalspeed(fpm)
•OAT(degreesC)
•Trueairspeed(knots)
•PitchAttitudeAngle(degrees)
•RollAttitudeAngle(degrees)
•LateralandVerticalGForce(g)
•GroundSpeed(kts)
•GroundTrack(degrees
magnetic)
•Latitude(degrees;geodetic;
+North)
•Longitude(degrees;geodetic;
+East)
•MagneticHeading(degrees)
•HSIsource
•Selectedcourse
•Com1/Com2frequency
•Nav1/Nav2frequency
•CDIdeection
•VDI/GP/GSdeection
•WindDirection(degrees)
•WindSpeed(knots)
•ActiveWaypointIdentier
•Distancetonextwaypoint(nm)
•Bearingtonextwaypoint
(degrees)
•Magneticvariation(degrees)
•AutopilotOn/Off
•AFCSroll/pitchmodes
•AFCSroll/pitchcommands
•GPSx
•GPShorizontalalertlimit
•GPSverticalalertlimit
•SBASGPShorizontalprotection
level
•SBASGPSverticalprotection
level
•FuelQty(right&left)(gals)
•FuelFlow(gph)
•FuelPressure(psi)
•Voltage1and/or2
•Amps1and/or2
•EngineRPM
•OilPressure(psi)
•OilTemperature(deg.F)
•ManifoldPressure(in.Hg)
•CHT
•EGT

Garmin G1000 Diamond DA42NG Specifications

General

Display Type	LCD
Resolution	1024 x 768 pixels
Manufacturer	Garmin
Aircraft	Diamond DA42NG
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Audio Panel	Yes, integrated
Operating System	Proprietary
Weather Radar	Optional
Power Supply	28 VDC
Screen Size	10.4 inches
Number of Displays	2
AHRS	Yes
Air Data Computer (ADC)	Yes
GPS	Yes
Transponder	Yes
Input Method	knobs
Navigation	VOR, ILS, GPS
Traffic Avoidance	TAS/TCAS
Terrain Awareness	Yes, TAWS
