Figure 8-3 SVS on the Primary Flight Display
SVS
Softkeys
Synthetic
Terrain
Pathways
Color
Matches CDI
Indicating
NAV Source
Flight
Path
Marker
Airport
Runway
Zero
Pitch Line
(ZPL) with
Compass
Heading
Marks
Airplane
Symbol
Selected
Altitude
NOTE: Pathways and terrain features are not a substitute for standard course and altitude deviation
information provided by the altimeter, CDI, and VDI.
PATHWAYS
Pathways provide a three-dimensional perspective view of the selected route of flight shown as colored
rectangular boxes representing the horizontal and vertical ight path of the active ight plan.  The box
sizerepresents700feetwideby200feettallduringenroute,oceanic,andterminalightphases.During
anapproach,theboxwidthis700feetoronehalffullscaledeviationontheHSI,whicheverisless.The
heightis200feetoronehalffullscaledeviationontheVDI,whicheverisless.Thealtitudeatwhichthe
pathwayboxesaredisplayedisdeterminedbythehigherofeithertheselectedaltitudeortheVNAValtitude
programmedfortheactivelegintheightplan(Figure8-4).
The color of the rectangular boxes may be magenta, green, or white depending on the route of flight and
navigation source selected. The active GPS or GPS overlay flight plan leg is represented by magenta boxes
thatcorrespondtotheMagentaCDI.Alocalizercourseisrepresentedbygreenboxesthatcorrespondtoa
greenCDI.Aninactivelegofanactiveightplanisrepresentedbywhiteboxescorrespondingtoawhiteline
drawnontheInsetmaporMFDmapindicatinganinactiveleg.
