VERTICAL SPEED MODE (VS)
InVerticalSpeedMode,theightdirectoracquiresandmaintainsaVerticalSpeedReference.Currentaircraft
vertical speed (to the nearest 100 fpm) becomes the Vertical Speed Reference at the moment of Vertical Speed
Mode activation.  This modemay be used for climb or descent to theSelected Altitude (shown above the
Altimeter) since Selected AltitudeCaptureModeisautomaticallyarmedwhenVerticalSpeedModeisselected.
WhenVerticalSpeedModeisactivatedbypressingthe VS Key,‘VS’isannunciatedingreenintheAFCSStatus
BoxalongwiththeVertical Speed Reference. The Vertical Speed Reference is also displayed above the Vertical
SpeedIndicator.AVerticalSpeedReferenceBugcorrespondingtotheVerticalSpeedReferenceisshownon
the indicator.
CHANGING THE VERTICAL SPEED REFERENCE
TheVerticalSpeedReference(shownbothintheAFCSStatusBoxandabovetheVerticalSpeedIndicator)
may be changed by:
•Usingthe NOSE UP/NOSE DN Keys
•Pressingthe CWS Button,hand-yingtheaircrafttoattainanewVerticalSpeedReference,thenreleasing
the CWS Button
Figure 7-8 Vertical Speed Hold Mode
Selected
Altitude Capture
Mode Armed
Vertical Speed
Mode Active
Vertical
Speed
Reference
Command Bars Indicate Climb to
Attain Vertical Speed Reference
Vertical
Speed
Reference
Bug
Vertical
Speed
Reference
Selected
Altitude
