MINIMUM DESCENT ALTITUDE/DECISION HEIGHT ALERTING
Foraltitudeawareness,abarometricMinimumDescentAltitude(MDA)orDecisionHeight(DH)canbeset
intheTimer/ReferencesWindowandisresetwhenthepoweriscycled.Whenactive,thealtitudesettingis
displayedtothebottomleftoftheAltimeter.Oncethealtitudeiswithintherangeofthetape,abugappears
atthereferencealtitudeontheAltimeter.Thefollowingvisualannunciationsoccurwhenapproachingthe
MDA/DH:
•Whentheaircraftaltitudedescendstowithin2500feetoftheMDA/DHsetting,theBAROMINboxappears
with the altitude in light blue text. The bug appears on the altitude tape in light blue once in range.
•Whentheaircraftpassesthrough100feetoftheMDA/DH,thebugandtextturnwhite.
•OncetheaircraftreachesMDA/DH,thebugandtextturnyellowandtheauralalert,“Minimums.Minimums”,
is heard.
Figure 2-36 Barometric MDA/DH Alerting Visual Annunciations
Yellow When Altitude Reached
White Within 100 ft
Barometric
Minimum
Box
Barometric
Minimum
Bug
Light Blue Within 2500 ft
Setting the barometric Minimum Descent Altitude/Decision Height and bug:
1) Press the TMR/REF Softkey.
2) Turn the large FMS Knob to highlight the Minimums field.
3) Turn the small FMS Knob to select BARO. Off is selected by default. Press the ENT Key or turn the large FMS
Knob to highlight the next field.
4) Use the small FMS Knob to enter the desired altitude from zero to 16,000 feet.
5) To remove the window, press the CLR Key or the TMR/REF Softkey.
Figure 2-37 Barometric MDA/DH
Alertingisinhibitedwhiletheaircraftisonthegroundanduntiltheaircraftreaches150feetabovetheMDA.
IftheaircraftproceedstoclimbafterhavingreachedtheMDA,onceitreaches50feetabovetheMDA,alerting
is disabled.
