Garmin G1000 Diamond DA42NG User Manual

Garmin G1000 Pilot’s Guide for the Diamond DA42NG
190-00-00962-02 Rev. A
404
HAZARD AVOIDANCE
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICESINDEX
6.9 TRAFFIC INFORMATION SERVICE (TIS)
WARNING : The Traffic Information Service (TIS) is intended for advisory use only. TIS is intended to help the
pilot locate traffic visually. It is the responsibility of the pilot to see and maneuver to avoid traffic.
NOTE: TIS is available only when the aircraft is within the service volume of a TIS-capable terminal radar
site. Aircraft without an operating transponder are invisible to both Traffic Advisory Systems (TAS) and TIS.
Aircraft without altitude reporting capability are shown without altitude separation data or climb descent
indication.
NOTE: TIS is disabled if a Traffic Advisory System (TAS) is installed.
TrafcInformationService(TIS)isdesignedtohelpindetectionandavoidanceofotheraircraft.TISusesthe
ModeStransponderforthetrafcdatalink.TISreceivestrafcinformationfromgroundstations,andisupdated
every5seconds.TheG1000displaysuptoeighttrafctargetswithina7.5-nmradius,from3000feetbelowto
3500feetabovetherequestingaircraft.TrafcisdisplayedusingthesymbologyshowninTable6-26.
TIS Symbol Description
Non-Threat Traffic
Traffic Advisory (TA)
Traffic Advisory Off Scale
Table 6-26 TIS Traffic Symbols
ATrafcAdvisory(TA)indicatesthatthecurrenttrackoftheintrudercouldresultinacollision.Whentrafc
meetstheadvisorycriteriafortheTA,asolidyellowcirclesymbolisgenerated.ATAwhichisdetected,butis
outsidetherangeofthemap,isindicatedwithamessageinthelowerleftcornerofthemapandahalfTAsymbol
at the relative bearing of the intruder.
TISalsoprovidesavectorlineshowingthedirectioninwhichthetrafcismoving,tothenearest45°.Trafc
informationforwhichTISisunabletodeterminethebearing(non-bearingtrafc)isdisplayedinthecenterofthe
TrafcMapPage(Figure6-162)orinabanneratthelowerleftcornerofmapsotherthantheTrafcMapPageon
whichtrafccanbedisplayed(Figure6-158).
Thealtitudedifferencebetweentherequestingaircraftandotherintruderaircraftisdisplayedabove/belowthe
trafcsymbolinhundredsoffeet.Iftheotheraircraftisabovetherequestingaircraft,thealtitudeseparation
appearsabovethetrafcsymbol;ifbelow,thealtitudeseparationappearsbelow.Altitudetrendisdisplayedas
anup/downarrow(forspeedsgreaterthan500fpmineitherdirection)totherightofthetargetsymbol.Trafc
symbols for aircraft without altitude reportingcapability appear without altitude separation or climb/descent
information.

Garmin G1000 Diamond DA42NG Specifications

General

Display Type	LCD
Resolution	1024 x 768 pixels
Manufacturer	Garmin
Aircraft	Diamond DA42NG
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Audio Panel	Yes, integrated
Operating System	Proprietary
Weather Radar	Optional
Power Supply	28 VDC
Screen Size	10.4 inches
Number of Displays	2
AHRS	Yes
Air Data Computer (ADC)	Yes
GPS	Yes
Transponder	Yes
Input Method	knobs
Navigation	VOR, ILS, GPS
Traffic Avoidance	TAS/TCAS
Terrain Awareness	Yes, TAWS
