Garmin G1000 Diamond DA42NG User Manual

Garmin G1000 Pilot’s Guide for the Diamond DA42NG
190-00962-02 Rev. A474
ADDITIONAL FEATURES
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICESINDEX
8.1 SYNTHETIC VISION SYSTEM (SVS) (OPTIONAL)
WARNING: Use appropriate primary systems for navigation, and for terrain, obstacle, and traffic avoidance.
SVS is intended as an aid to situational awareness only and may not provide either the accuracy or reliability
upon which to solely base decisions and/or plan maneuvers to avoid terrain, obstacles, or traffic.
The optional SyntheticVisionSystem(SVS)isavisualenhancementtotheG1000IntegratedFlightDeck.SVS
depictsaforward-lookingattitudedisplayofthetopographyimmediatelyinfrontoftheaircraft.Theeldof
view is 30 degrees to the left and 35 degrees to the right. SVS information is shown on the Primary Flight Display
(PFD),orontheMultifunctionDisplay(MFD)inReversionaryMode(Figure8-113).Thedepictedimageryis
derived from the aircraft attitude, heading, GPS three-dimensional position, and a nine arc-second database of
terrain, obstacles, and other relevant features. The terrain data resolution of nine arc-seconds, meaning that
theterrainelevationcontoursarestoredinsquaresmeasuringninearc-secondsoneachside,isrequiredforthe
operationofSVS.Lossofanyoftherequireddata,includingtemporarylossoftheGPSsignal,willcauseSVSto
bedisableduntiltherequireddataisrestored.
The SVS terrain display shows land contours (colors are consistent with those of the topographical map display),
largewaterfeatures,towers,andotherobstaclesover200’AGLthatareincludedintheobstacledatabase.Cultural
featuresonthegroundsuchasroads,highways,railroadtracks,cities,andstateboundariesarenotdisplayed
evenifthosefeaturesarefoundontheMFDmap.Theterraindisplayalsoincludesanorth–southeast–westgrid
with lines oriented with true north and spaced at one arc-minute intervals to assist in orientation relative to the
terrain.
The Terrain-SVS is integrated within SVS to provide visual and auditory alerts to indicate the presence of terrain
and obstacle threats relevant to the projected flight path. Terrain alerts are displayed in red and yellow shading
on the PFD.
Theterraindisplayisintendedforsituationalawarenessonly.Itmaynotprovidetheaccuracyordelityon
whichtobasedecisionsandplanmaneuverstoavoidterrainorobstacles.Navigationmustnotbepredicated
solelyupontheuseoftheTerrain–SVSterrainorobstacledatadisplayedbytheSVS.
The following SVS enhancements appear on the PFD:
•Pathways
•FlightPathMarker
•HorizonHeadingMarks
•TrafcDisplay
•AirportSigns
•RunwayDisplay
•TerrainAlerting
•ObstacleAlerting

Garmin G1000 Diamond DA42NG Specifications

General

Display Type	LCD
Resolution	1024 x 768 pixels
Manufacturer	Garmin
Aircraft	Diamond DA42NG
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Audio Panel	Yes, integrated
Operating System	Proprietary
Weather Radar	Optional
Power Supply	28 VDC
Screen Size	10.4 inches
Number of Displays	2
AHRS	Yes
Air Data Computer (ADC)	Yes
GPS	Yes
Transponder	Yes
Input Method	knobs
Navigation	VOR, ILS, GPS
Traffic Avoidance	TAS/TCAS
Terrain Awareness	Yes, TAWS
