190-00962-02 Rev. A
Garmin G1000 Pilot’s Guide for the Diamond DA42NG
379
HAZARD AVOIDANCE
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICES INDEX
SYSTEM STATUS
TheradarmodeisannunciatedintheupperleftcorneroftheWeatherRadarPage.Additionalinformation
maybedisplayedinthecenteroftheWeatherRadarPageasabannerannunciation.
Radar Mode
Radar Mode Annunciation Box
Center Banner Annunciation
Standby STANDBY STANDBY
Standby (During Warm-Up) STANDBY
WARM-UP
XX
(XX indicates number of seconds
remaining in warm-up)
Weather WEATHER None
Ground Mapping GROUND MAPPING None
Off OFF OFF
Radar Failed* FAIL RADAR FAIL
* See Table 6-17 for additional failure annunciations
Table 6-15 Radar Modes on the Weather Radar Page
Thesystem displays the status of the radar antenna stabilizationfeaturein theupperrightcorner of the
WeatherRadarPage.
Radar Antenna
Stabilization Status
Description
STAB ON Antenna stabilization is selected on.
STAB OFF Antenna stabilization is selected off.
STAB INOP
The radar is not receiving pitch and roll information.
The antenna stabilization feature is inoperative.
Table 6-16 Antenna Stabilization Annunciations on the Weather Radar Page
Iftheradarunitfails,anannunciationastothecauseofthefailureisshownasabannerinthecenterofthe
WeatherRadarPage.
Weather Radar
Page Center Banner
Annunciation
Description
BAD CONFIG The radar configuration is invalid. The radar should be serviced.
RDR FAULT The radar unit is reporting a fault. The radar should be serviced.
RADAR FAIL
The system is not receiving valid data from the radar unit. The system
should be serviced.
Table 6-17 Abnormal Radar Status Annunciations on the Weather Radar Page
