UNUSUAL ATTITUDES
When the aircraft enters an unusual pitch attitude, red chevrons pointing toward the horizon warn of extreme
pitch.ThechevronsaredisplayedontheAttitudeIndicator,startingat50˚aboveand30˚belowthehorizon
line.
Figure 2-39 Pitch Attitude Warnings
Nose High
Nose Low
Ifpitchexceeds+30˚/-20˚orbankexceeds65˚,someinformationdisplayedonthePFDis removed. The
Altimeterand Airspeed,Attitude,VerticalSpeed,andHorizontal Situationindicators remainon thedisplay
andtheBearingInformation,Alerts,andAnnunciationwindowscanbedisplayedduringsuchsituations.The
followinginformationisremovedfromthePFDandtheirsoftkeysaredisabledwhentheaircraftexperiences
unusual attitudes:
•TrafcAnnunciations
•AFCSAnnunciations
•FlightDirectorCommandBars
•InsetMap
•OutsideAirTemperature(OAT)
•WindData
•SelectedHeadingReadout
•SelectedCourseReadout
•TransponderStatusBox
•SystemTime
•PFDSetupMenu
•Windowsdisplayedinthelower
right corner of the PFD:
–Timer/References
–NearestAirports
– Flight Plan
– Messages
– Procedures
•Minimum Descent Altitude/
DecisionHeightReadout
•Vertical Deviation, Glideslope,
and Glidepath Indicators
•AltimeterBarometricSetting
•SelectedAltitude
•VNVTargetAltitude
•DMEWindow
•TrueAirspeed
•MarkerBeaconIndicator
•MetricAltitudeDisplay

Garmin G1000 Diamond DA42NG Specifications

General

Display Type	LCD
Resolution	1024 x 768 pixels
Manufacturer	Garmin
Aircraft	Diamond DA42NG
Primary Flight Display (PFD)	Yes
Multi-Function Display (MFD)	Yes
Audio Panel	Yes, integrated
Operating System	Proprietary
Weather Radar	Optional
Power Supply	28 VDC
Screen Size	10.4 inches
Number of Displays	2
AHRS	Yes
Air Data Computer (ADC)	Yes
GPS	Yes
Transponder	Yes
Input Method	knobs
Navigation	VOR, ILS, GPS
Traffic Avoidance	TAS/TCAS
Terrain Awareness	Yes, TAWS
