Garmin G1000 Diamond DA42NG User Manual

Garmin G1000 Pilot’s Guide for the Diamond DA42NG
190-00962-02 Rev. A
54
FLIGHT INSTRUMENTS
SYSTEM
OVERVIEW
FLIGHT
INSTRUMENTS
EIS
AUDIO PANEL
& CNS
FLIGHT
MANAGEMENT
HAZARD
AVOIDANCE
AFCS
ADDITIONAL
FEATURES
APPENDICESINDEX
VERTICAL DEVIATION
NOTE: The Glidepath Indicator is only shown for aircraft with GIA 63W Integrated Avionics Units when
SBAS is available.
TheVerticalDeviationIndicator(VDI)isamagentachevronindicatingthebaro-VNVverticaldeviationwhen
VerticalNavigation(VNV)isbeingused.TheVDIappearsinconjunctionwiththe“TODwithin1minute”
alert. The VDI is removed from the display if vertical deviation becomes invalid. See the Flight Management
SectionfordetailsonVNVfeatures,andrefertoSection2.2,SupplementalFlightData,formoreinformation
aboutVNVindicationsonthePFD.
The Glideslope Indicator appears to the left of the Altimeter whenever an ILS frequency is tuned in the
activeNAVeld.AgreendiamondactsastheGlideslopeIndicator,likeaglideslopeneedleonaconventional
indicator.Ifalocalizerfrequencyistunedandthereisnoglideslope,“NOGS”isdisplayedinplaceofthe
diamond.
TheglidepathisanalogoustotheglideslopeforGPSapproachessupportingSBASverticalguidance(LNAV+V,
L/VNAV,LPV).WhenanapproachofthistypeisloadedintotheightplanandGPSistheselectednavigation
source, the Glidepath Indicator appears as a magenta diamond. If the approach type downgrades past the final
approachx(FAF),“NOGP”isdisplayedinplaceofthediamond.
Full-scale deflection of two dots is 1000 feet.
Glipepath
Indicator
Glidepath Indicator
Figure 2-10 Vertical Speed and Vertical Deviation Indications
Glideslope
Indicator
Marker
Beacon
Annunciation
Glideslope Indicator
Vertical Speed and Deviation
Indicator (VSI and VDI)
Required
Vertical
Speed
Indicator
Vertical
Speed
Indicator
Vertical
Speed
Pointer
VNV Target
Altitude
Vertical
Deviation
Indicator
