Revision C CASE 6-29
2060290-201
Test End Phase
Test End Phase
Overview
1. Press the test end button to end the test and start the test end
phase.
2. Click Yes to confirm the test end. The Interpretation window appears
with the patient's ECG waveforms below.
Note
After you press the test end button, the following happens:
The system no longer acquires and stores ECG measurement
data.
The clocks stop.
Workload, speed, and grade no longer display.
Operating Steps
1. Enter or select the Reasons for Termination (multiple selections are
permitted).
2. Select the Angina Index which is necessary to calculate the Duke
Treadmill Score.
3. Enter or select summary statements (multiple selections are
permitted).
4. Enter the Conclusion.
5. Click Modify... to edit the Duke Treadmill Score (see “Duke
Treadmill Score” on page B-9). Enable the Duke TM Score : to
include it in the Test Results and in the Final Report.
6. Confirm the test results.
7. Click OK to clear the window. The Interpretation window and the
test end menu tabs appear.
To Next Page
