12-12 CASE Revision C
2060290-201
Exercise Test Setup
Exercise Test Setup
The settings specific to the exercise test modality can be entered either
from the exercise test pre-acquisition screen where you click Setup to
display the setup menu, or from the General tab of the System
Configuration (see “General Tab” on page 12-40).
Writer Tab
The Writer tab with the writer settings is already on top.
A Click to print the exercise test setup.
B Click to select the writer gain.
C Click to select the writer speed.
D Click to select writer for In-Test Reports.
E
Select or deselect automatic in-test reports configured in the Protocol
Editor (see “Protocol Editor Tab” on page 12-19).
F
Select or deselect display of the ST Table in the 12-lead reports.
G Define output of manually acquired in-test reports: Print, Print&Save or Save.
H Select peak exercise report type: none, Medians, 12-Lead ECG.
I Select rhythm lead for viewing and recording.
J Select 12SL report format.
K Select Medians report:
Select the rhythm lead for Linked Medians at I.
Select the leads for Median H1 at N.
L Select Rhythm/Recall report format.
M Select 12-Lead report format.
N Select H1 ECG leads.
To Next Page
