12-10 CASE Revision C
2060290-201
Resting ECG Setup
Report Editor
The Configured Report Editor allows you to create a maximum of 10
templates (e.g. letter to referring physician). Two templates (Reports 1
and 2) are preconfigured and cannot be changed.
Click Modify... on the Final Report tab to display the Configured Report
Editor window.
You can enter text and insert report items from a list (e.g., patient name,
heart rate). At the time the report is printed the program will replace
these report items with the actual data.
1. Click to select and open a report template.
2. Click in the window and type the text.
3. Click Insert Report Items to open the list of available data fields and
select an item by double-clicking.
4. Highlight the text and select the font.
5. Select the font size.
6. Select the font format: bold, italics or underlined
.
7. Select a color from the color palette A and click the colored bar.
8. Select the paragraph format: left flush, right flush, or centered.
9. Click Logo to open the logo window.
97A-R
12 104 5 6711 3 9
8
12
To Next Page
