Revision C
CASE
12-51
2060290-201
System Configuration
Note
Access to the
Date/Time Properties
dialog is restricted to authorized
system users.
Procedure Statistics
Click
Procedure Statistics
(
N
on the
General
tab) to display the setup
window.
1.
Enter the date range for the statistical an
alysis.
2.
Select the pe
riod (month, quarter, year).
3.
Click to calculate the statistics.
4.
Click to export the da
ta to Microsoft Excel.
932A
3
14
2
282
284
