Revision C CASE 6-39
2060290-201
After the Test — Post Test Review
Sample Cardiac Cycles
Overview
This screen shows the median complexes collected at each stage,
beginning with the pretest phase.
Note
Reanalyze the sample cardiac cycles as described under “Reanalysis”
on page 6-41.
A Click the lead label to change the displayed leads.
B Click to display the Sample Cardiac Cycles.
C Click to view more sample cardiac cycles.
D Click to show and hide the measurement marks.
E Select the speed of the displayed medians.
F Select the gain for the displayed medians.
G Select the number of lines (1, 3, 6).
H Number of medians shown per stage:
: All cardiac cycles (at intervals of 30 seconds)
: only one cardiac cycle
