5-26 CASE Revision C
2060290-201
Post Test Review
Report Printout
Click the Print button to print the report. The print setup window opens
where you can temporarily adjust the settings for the printout. Refer to
section “Final Report Tab” on page 12-9 for details on changing the setup
permanently.
1. Select the documents to be included in the report
Configured Report
10-second ECG (up to 3 different formats, with or without
Interpretation or ACI-TIPI score)
two more formats of the 10-second ECG
Medians
Vector Loops.
2. Select the lead format for the 10-second ECG.
3. Select the number of copies to print.
4. Choose the leads if you selected the Swedish Median H1 format.
5. Select the rhythm leads.
6. Select whether or not the Median H1 report is to include the
measurement marks.
7. Select the gain.
8. Select the printer.
9. Click the Print button to initiate the printout.
