Revision C CASE 12-17
2060290-201
Exercise Test Setup
Lead Sequence Tab
Click the Lead Sequence tab to open the window.
Lead sequence is the assignment of ECG leads to the writer or screen
channels.
You can change the lead sequences according to your needs and save
them under the same name or under a new name. You may also define
different lead sequences for the screen display and the printouts.
Note
The first two lead sequences are fixed and cannot be modified.
Modifying the Lead Sequence
1. Select the number of monitored leads. These are the leads to be
recorded.
2. Select a Lead Sequence.
3. Open the list box of the channel where you want to record another
lead and select.
4. Enter the lead label.
5. Select the lead for screen display (only possible after definition of the
lead sequence).
