Page #55 background imageLoading...
Page #55 background image
Revision C CASE 3-5
2060290-201
Applying Electrodes
Applying Electrodes
Lead Labels on the Acquisition Module
CAUTION
Proper Leadwire Connection — Improper connection will
cause inaccuracies in the ECG.
Trace each individual leadwire from its acquisition
module label to the colored connector and then to the
proper electrode to ensure that it is matched to the
correct label location.
CAM-14
AHA Label IEC Label
RL N
RA R
LA L
LL F
V1 C1
V2 C2
V3 C3
V4 C4
V5 C5
V6 C6
A1 A1
A2 A2
A3 A3
A4 A4
