Revision C CASE 12-35
2060290-201
Spirometry Setup
Spirometry Setup
The settings specific to the spirometry modality can be entered either
from the spirometry acquisition screen where you click Setup to display
the setup menu, or from the General tab of the System Configuration (see
“General Tab” on page 12-40).
Acquisition Tab
The Acquisition tab is already on top.
Note
Check the entered ambient conditions each day. The program needs
this information for BTPS correction (Body Temperature Pressure
Saturated), i.e., the measuring values are referred to an ambient
pressure and saturation with water vapor at a body temperature of
37 °C.
Note
Exiting the spirometry setup menu with OK confirms all data and
the PT code. At the same time, date and time in the PT Code line on
the acquisition screen will be updated.
A Click to print the spirometry test setup.
B Select the Equation for Reference Value Calculation.
C Select the Interpretation Mode.
D Select the Measurement Mode.
E Select the PT Code.
F
Select to print the report automatically after the test.
G
Select if you want to hear a beep at the end of expiration in the ATS mode.
H Enter the atmospheric pressure.
I Enter the relative air humidity.
J Enter the ambient temperature (SpiroSoft only).
K Enter the respiratory air temperature for the VC/FVC test (LF 501 only).
