6-56 CASE Revision C
2060290-201
After the Test — Post Test Review
Report Printout
Click the Print button to print the report. The print setup window opens
where you can temporarily adjust the settings for the printout. Refer to
section “Final Report Tab” on page 12-23 for details on changing the
setup permanently.
1. Select the documents for the report (Configured Report, Tabular
Summary, Graded Exercise Summary Report etc.): In the Trend
Reports section, select the report formats to print.
2. Select the gain.
3. Select the Configured Report format (see section “Report Editor” on
page 12-10).
4. Select the number of copies for each report section.
5. Select the printer.
6. Check the total number of pages.
7. Initiate the printout.
8. Click Delete selections to cancel the selections.
Note
Select the ECG Grid option if you print on plain paper.
