GE CASE V6.7 User Manual

Revision C CASE 12-29
2060290-201
Exercise Test Setup
ST/Medians / 12SL Tab
Click the ST/Medians / 12SL tab to display the window for setup of ST
measurement and 12SL.
922A-S
A B C D E F G H
A Click option button to select calculation method for E and J points.
B Click option button to select calculation method for post-J point.
Manual: set post-J point at D
Auto: select formula at C.
C Select formula for calculation of post-J point.
D Manually select post-J value.
E
Select or deselect the ST Criteria.
F Click option button to select ST Slope criteria.
G Select the max. ST elevation/depression (when the limit is reached, a
message appears on the acquisition screen).
H
Select or deselect the 12SL Criteria.
