GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 4-2 - General Procedure 4-23
4-3-9 Peripheral Checks
Check that peripherals work as described below:
4-3-9-1 Peripheral/Option Checks
If any peripherals or options are not part of the system configuration, the check can be omitted. Refer
to the User Manual for a list of approved peripherals/options.
Table 4-5 Peripheral checks
Step Task to do Expected Result(s)
1.
Press Freeze Stop image acquisition.
2.
Press (P1) or (P4) on the Control panel
The image displayed on the screen is
printed on B&W or Color printer depending
on the key assignment configuration.
Table 4-6 GE Approved Peripheral/Hardware Option Functional Checks
Step Item Description
1VCR
Verify record/playback capabilities of the VCR. Clean heads and covers if necessary.
2 B/W Printer
Verify hardcopy output of the B/W video page printer. Clean heads and covers if necessary.
3 Color Printer
Verify hardcopy output of the Color video page printer. Clean heads and covers if necessary.
4 DICOM
Verify that DICOM is functioning properly. Send an image to a DICOM device.
5 InSite/iLinq
Verify that InSite is functioning properly. Ensure two-way remote communications.
(Warranty & Contract Customers only)
6 Camera
Verify hardcopy output of the film camera. Clean as necessary.
7 Footswitch
Verify that the footswitch is functioning as programed. Clean as necessary.
8ECG
Verify basic operation with customer
9 3D Probe
Ask Engineering about Calibration Check for 3-D
