GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 5-8 - Monitor Video Specification 5-45
5-8-2-4 NTSC EIA
5-8-3 SVHS and Composite Video
5-8-3-1 Basic DC Parameters
General SVHS-luma SVHS-croma Composite RGB B&W
Line/field: 525/60
FH: 15734 Hz
FV: 59.94 Hz
Bandwidth: Min.
4.2MHz (luma)
Signal: 92.5 IRE
(from black level)
100% amplitude
Blanking setup:
7.5 IRE
Sync: 40 IRE
Burst amplitude:
+/- 20 IRE, 9
cycles
Fsc: 3.579545
MHz 100%
saturation
Summed luma
and croma
Signal: 0-700
mV
Comp sync/H
sync/ V sync: 0.3
- 4 Vpp
SVHS luma
Parameters NTSC PAL
White relative to blank 714 +/- 7 mV 700 +/- 7 mV
Black relative to blank 54 +/- 7 mV 0
Sync relative to blank -286 +/- 7 mV -300 +/- 7 mV
Burst amplitude (nominal, p-p) 286 +/- 7 mV 300 +/- 7 mV
