GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-6 Section 9-4 - Renewal Parts List For R7.5.x
9-4-2 R7.5.x Parts
The following parts are new for R7.5.x but other parts are common with BT06. For Common Parts not
listed here, refer to Section 9-5 - Renewal Parts List For BT07.
Figure 9-1 R7.5.x Parts
Table 9-5 V75x Parts
Item Part Name Part Number Description Qty FRU
- LOGIQ7 R7.5.0 Application Software CD 5252012-3
Application software in CD. This part never went to
circulation.
--
1 LOGIQ7 R7.5.1 Application Software CD 5252012-4 Application software in CD 1 1
2 19Inch LCD Monitor for LOGIQ 5212808 19inch LCD Monitor/ Front & Rear Panel 1 1
3 L9 19 In. LCD Speaker Assembly 5199460 L/R Speakers and Bracket 1 1
4 COVER VESA ASSY L7 5248133 LCD Rear cover & Label 1 1
5 19 LCD LATCH-N-LOK CABLE 5240769 3pin to Powered USB conversion 1 1
2
3
4
5
6
7
8
9
10
11
12
13
14
