DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
5-16 Section 5-4 - Block Diagrams and Theory
5-4-3-3 BEP4 Power Connections
Figure 5-40 BEP4 AC line and DC line connection
Connections
40mm
FAN
20(10x2)pin connector to motherboard
4(2x2)pin connector
to motherboard
80mm
FAN
HDD
BulkHead
ATX Power Supply
USP Battery
4(4x1)pin connector
4(4x1)pin
connector
4(4x1)pin
connector
2pin
connector
Not Used
4(4x1)pin connector
small 4(4x1)pin connector
small 2pin connector
AC100V
SW
4(4x1)pin
connector
Connector
Panel
24V
5V,12V
5V,12V
12V
3.3V,5V,12V,-5V,-12V,5VSTB
5VSTB
6(6x1)pin
connector
A02-4FANA02-4FAN
A03-8FANA03-8FAN
A01-HDDA01-HDD
5V,12V
A06-UPSA06-UPS
A05-BULKA05-BULK
A04-CNPNLA04-CNPNL
6(3x2)pin
connector
UPS
Ctrl
FAN
To DVD
only 12V
only 12V
5VSTB to
MDBRG2S
To LED of
Console Switch
Pin header
for Power LED
Pin header
for HDD LED
JB05
JB04
JB03
JB02
To OP Panel
HDD LED
CPU Fan
Not Used
CPU Cooling
Fan
