DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
3-22 Section 3-5 - Installation Paperwork
3-5-1-1 Rear Panel Connector (cont’d)
Pin Assignment of Digital Int. Connector
Connector: 6-pin
Pin Assignment of Ethernet
Connector: RJ-45 Modular, 8-pin
Pin Assignment of Insite
Connector: RJ-11 Modular, 6-pin
Table 3-13 Pin Assignment of IEEE-1394 Connector)
Pin No Output Signal Description
1 VP 1394 Power Supply
2 VG 1394 Power Ground
3 TPB 1394 Data B (-)
4 TPB 1394 Data B (+)
5 TPA 1394 Data A (-)
6 TPA 1394 Data A (+)
Table 3-14 Pin Assignment of Ethernet Connector
Pin No Output Signal Description
1 ETHER TD Ethernet TD+
2 ETHER TD Ethernet TD-
3 ETHER RD Ethernet RD+
6 ETHER RD Ethernet RD-
Others NC Non-connection
Table 3-15 Pin Assignment of Insite Connector
Pin No Output Signal Description
2 TEL L4 Telephone L4
3 TEL L2 Telephone L2
4 TEL L1 Telephone L1
5 TEL L3 Telephone L3
Others NC Non-connection
4
1 3 5
2 4 6
5
8 1
6
8 1
