Section 5-2 - Hardware Compatibility Matrix 5-7
5-2-1-6 Power Units
Figure 5-31 Power Units- FRU Compatibility
R8.0.x R8.0.x R8.0.x R8.0.x
Latest Software
SW Upgraded BT09 (w BT02/BT03 console)
SW Upgraded BT09 from BT04/BT06/BT07
19 inch LCD Upgraded BT09 from 17 inch LCD
R8.0.X (BEP4)
comment
2304538-4 P9534WP AC POWER BOX 200V
Y
N N N Include AC BOX, AC Code, and extention cable
2384371 P9534XL AC POWER BOX ASSY JPN
Y
NNN
Include AC BOX, AC Code, and extention cable
(Only for Japan)
2384370 P9534XP AC POWER BOX ASSY 100V
Y
NNN
Include AC BOX, AC Code, and extention cable
(not for Japan)
2304624 P9538JC CONSOLE FAN SSY
NNNN
5117493 CONSOLE FAN ASSY 2 CSL L7
N
YYY
5122614 CONSOLE FAN ASSY-A UPG L7
Y
N N N Only for Upgraded BT04 from BT01/02/03
2372387 P9534XH L7HV-SVC
YYYY
2334197 P9534WU LV-2 SERVICE UNIT
Y
N N N Compatible with 2283531 (LV)
2292209 P9534WF SSR PANEL
Y
NNN
2315585 P9534WR FUSE FOR SSR PANEL
Y
NNN
2283530 P9534WB MAIN TRANS
Y
NNN
2373331-2 MAIN TRANS2 ASSY CSL L7
YYYY
5117721 LV-04 UNIT MAIN PS L7
N
YYY
5118824-2 LV-04 UNIT with Cables
N
YYY
Noise Improvement
5117723 NF INLET ASSY MAIN PS L7
N
YYY
5117724 AC IN OUT 100V MAIN PS L7
N
YYY
5117725 AC IN OUT 200V MAIN PS L7
N
YYY
5118052 AC IN200 OUT100 ASSY MAIN PS L7
N
YYY
Only for Korea System
5117726 SSR PCB ASSY MAIN PS L7
N
YYY
5117727 FUSE HOLDER MAIN PS L7
N
YYY
5117728-3 CONN ASSY MAIN PS L7
N
YYY
5119119 SSR-HLV CABLE
N
YYY
5119120 SSR-AC PANEL CABLE
N
YYY
5119121 VOLTAGE SEL CABLE
N
YYY
2301858-3 ? PW SW ASSY
N
YYY
5117493 CONSOLE FAN ASSY2
N
YYY
5117491 FAN CABLE BRAKET ASSY
N
YYY
FRU Part# Description
FRU compatibility
BT09 ～
