DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
9-2 Section 9-3 - Renewal Parts List For BT09
Section 9-3
Renewal Parts List For BT09
This section describes the BT09 system FRU.
9-3-1 BT09, 19inch LCD: Equipment Models Covered in this Chapter (LOGIQ 7)
Table 9-2 Material List
Part Name Part Number Quantity Description
OPERATOR CONSOLE ASSY 5309921 1 100V, NTSC
OPERATOR CONSOLE ASSY 5309922 1 1 120V, NTSC
OPERATOR CONSOLE ASSY 5309923 1 1 220V, PAL
OPERATOR CONSOLE ASSY 5309924 1 220V, NTSC
LOGIQ7 R8.0.0 Application Software CD 5311031-3 111111
LOGIQ7 Ghost DVD for BECOMP4 5305206-3 111111
LOGIQ7 BT09 eDoc CD 5307396-200 111111
LOGIQLEAN MIDDLE 2369384 1
MSDS FOR KAO ACOUSTIC GEL 2384010 1
GEL AQUASONIC GEL U0403BD 11111
PARKER AQUASONIC100 2384142 11111
CD-R Media 700MB 5118386 111111
DVD-R 4.7GB 8 x Speed media 5160800-2 111111
KEY LABEL2 2360321 111111
LOGIQ 7 WEEE instruction 5143413 111111
WARRANTY CARD P9889AH 1
L7 Tempu-Bunsho for R6.5.X 5182547 1
AIUM Safety Pamphlet 5118349 1
AIUM Safety Pamphlet License 5123992 1
AC CORD 100V JPN 2371416 1
AC CORD 100V USA 2371417 1 1
AC CORD 200V EU 2371418 1 1
AC CORD 200V CHIN 2371415-2 1
P9538UA POWER CABLE TAG 2304574 1 1
SFDA LABEL L7 5149899 1
CAUTION TEL LABEL L7 2290996-3 11111
CAUTION TEL LABEL CHINA L7 2290996-4 1
P9524QE ETL.ETL-C LABEL 2135339 1 1 1 1
SONIC AuthorScript Data SDK Software
License
5178485
111111
CrossBeam Option 2394377 111111
SRI Option 5119471 111111
Caution sheet for Power cables - US 5180867 1
CHINA RoHS EFUP 20 LABEL 5196197 1
LOGIQ 7 Ceritification of Quality
Inspection for China
5229809
1
L7 L7P LS6 Addendum for Guidance and
manufacturer's declaration
5197395
111111
VERMONT HG LABEL 5241494 333333
LOGIQ7 V750 STYLE_J LCD JPN (5304556)
LOGIQ7 V750 STYLE_J LCD USA (5304556-2)
LOGIQ7 V750 STYLE_J LCD EU (5304556-3)
LOGIQ7 V750 STYLE_J LCD KOREA (5304556-4)
LOGIQ7 V750 STYLE_J LCD ASIA120(5304556-5)
LOGIQ7 V750 STYLE_J LCD ASIA220(5304556-6)
