GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
Section 9-5 - Renewal Parts List For BT07 9-11
9-5-4 BT07 Parts
The following parts are new for BT07, but other parts are common with BT06. For Common Parts not
listed here, refer to Section 9-6 - Renewal Parts List For V65x.
Figure 9-2 BT07 Parts
Table 9-9 V65x Parts
Item Part Name Part Number Description Qty FRU
1
LOGIQ7 Base System Software Load
Image for R7.0.0
5191839-2 Ghost image in DVD 1 1
2 LOGIQ7 Application Software R7.0.0 5191939-4 Application software in CD 1 1
3 FRU_Parts_LCD_CABLE_DUCT_ASSY 5139307-3 LCDPart / Compatible to BT04 1 1
4
FRU_Parts.LCD_TOP_BOTTOM_DSUB
_CABLE_ASSY
5198733
LCDPart / Compatible to BT04 ; replaces
5125391
1 1
5 DVI_CABLE_TOP_LCD_L7 5189828 LCDPart / Compatible to BT04 1 1
3
5
