GE LOGIQ 7 Service Manual

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
5-10 Section 5-2 - Hardware Compatibility Matrix
5-2-2-2 BT09_SV_BEP4 Configuration Variationos
Figure 5-34 BT09 Configuration Variations
N/A
R8.x.x
R8.x.x
Software NoteConsoleConfig
N/A
BT04/BT06/
BT07 base
BT04/BT06/B
T07/BT09
base
MD-3000 USB
Upgraded to BT09
(BEP3)
BT09 Original
(BEP4)
・Label “RS232C Not Available” on back
・Utility Menu shows Ghost Part Number
・NO Rear Panel markings
・Utility Menu shows Ghost Part Number
・REAR Panel have GPN printed :
5304518 : REAR CONN4 ASSY L7
N/A
R8.x.x
R8.x.x
Software NoteConsoleConfig
N/A
BT04/BT06/
BT07 base
BT04/BT06/B
T07/BT09
base
MD-3000 USB
Upgraded to BT09
(BEP3)
BT09 Original
(BEP4)
・Label “RS232C Not Available” on back
・Utility Menu shows Ghost Part Number
・NO Rear Panel markings
・Utility Menu shows Ghost Part Number
・REAR Panel have GPN printed :
5304518 : REAR CONN4 ASSY L7
RS232C Not Available
BEP4
MD-3000 USB
