GE LOGIQ 7 Service Manual

GE HEALTHCARE
DIRECTION 2286865, REVISION 14 LOGIQ™ 7 SERVICE MANUAL
1-16 Section 1-2 - Important Conventions
1-3-7 Label Locations (For BT03 or lower)
NOTE: For the symbols shown in the illustration below, refer to previous pages in this chapter.
1.) Possible Shock Hazard
2.) Caution for devices near by the equipment
3.) Caution for Transportation
4.) Prescription Devices (For USA Only)
5.) CE Marking of conformity
6.) CISPR
7.) Voltage Range
8.) Signal Ground Point Label
9.) Power Indication Label
10.)Caution for Grounding Reliability (For USA, Canada and Japan)
Figure 1-4 OUTSIDE MARKINGS OF LOGIQ™ 7 For BT03
or lower (Back Side)
1.
3.2.
4.
5.
6.
10.
9.
8.
7.
